2 T/H Two-Stage Reverse Osmosis Water Treatment Equipment

This equipment is a two-stage reverse osmosis (RO) water treatment system with a rated product water flow rate of 2 tons per hour (2000 liters per hour). It is suitable for industrial and commercial high-purity water production applications requiring both high water quality and relatively large water volume.

The system adopts a two-stage RO series process: the product water from the first-stage RO flows into an intermediate tank, and is then pumped by the second-stage high-pressure pump into the second-stage RO membrane module for secondary desalination. Two-stage RO achieves a higher desalination rate (typically ≥99%), with product water conductivity controlled below ≤2 μS/cm, ensuring stable and reliable water quality.

Applications:

• Pharmaceutical industry: Water for injection, purified water, oral liquid, large-volume parenteral production

• Food & beverage: High-purity bottled water, mineral water, beverage ingredient water, dairy processing water

• Electronics industry: Electronic components, semiconductor, LCD panel cleaning water

• Chemical industry: Fine chemicals, cosmetics, process pure water

• Power industry: Boiler feed water

• Laboratories: Analytical testing, research water

• Brewing industry: High-end liquor and beer blending water

Main Components:

• Pre-treatment unit: Multi-media filter, activated carbon filter, water softener (or scale inhibitor dosing system), cartridge filter (5μm)

• First-stage RO unit: First-stage high-pressure pump, first-stage RO membrane modules

• Second-stage RO unit: Intermediate tank, second-stage high-pressure pump, second-stage RO membrane modules

• Post-treatment unit (optional): UV sterilizer, ozone generator, TOC reducer, cartridge filter

• Control system: Online conductivity meter, flow meter, pressure gauge, PLC fully automatic control, touch screen operation, remote monitoring (optional)

Features:

• Product water flow: 2 T/H, suitable for medium-scale continuous water demand

• Desalination rate: ≥99%, product conductivity ≤2 μS/cm

• Two-stage design ensures stable water quality and strong anti-shock capability

• High degree of automation: PLC fully automatic control with auto start/stop, automatic flushing, low water protection, auto-stop when tank is full, online water quality monitoring

• 304/316L stainless steel piping and frame, corrosion-resistant, hygienic and safe

• Modular design for easy expansion and maintenance

• Optional energy recovery device to reduce operating costs
